DRY ICE 1.5K 50mm LEMON
The DRY ICE 1.5K 50mm OPTI cryostat is a cryogen-free top loading variable temperature system with neutron access. The VTI is designed with a thinned Aluminium, Vanadium or Mylar tail-set to give the ultimate beamline access combined with a wide range of sample manipulation and fast sample change times.
This is an excellent general research tool for beam-line spectroscopy applications at <1.5K. It can easily be upgraded with He3 or dilution inserts to lower base temperature further.
ICE offer to tailor this cryostat to suit your exact requirements.
FEATURES
SPECIFICATION
| Temperature range | 1.5-420K (800K option) |
| Temperature Stability | ±10mK below 10K, ±20mK between 10-50, ±50mK between 50-100K, ±100mK for temperatures ≥100K |
| Sample environment | Dynamic / static Helium exchange gas or vacuum |
| Vibration at sample | < 10 µm (low vibration options available) |
| Cool down time to | 5hrs at 100K |
| Wiring | DC, RF and fiber optic options available |
| Optical access | Multiple window options available |
| Base temperature | 1.5K |
| Hold time | Continuous |
| Temperature controller | Lakeshore 336 as standard |
| Magnetic Field | Special Beamline magnets available (Contact for info) |
